3810 Series
Performance and power for the campus and branch
Powerful Aruba Advanced Layer 3 switch series with backplane stacking, low latency and resiliency for the most demanding campus and branch networks.
No matter how devices connect, Aruba Dynamic Segmentation automatically enforces consistent policies across the wired and wireless networks, to keep traffic secure and separate.
Based on a powerful Aruba ASIC and ready for high-speed APs with HPE Smart Rate multi-gigabit Ethernet, the 3810 access solution is ideal for enterprises, SMBs, and branch office networks.
✓ Worldwide express shipping
✓ Unmatched customer support
802.11ac-ready wired network
Multi-gigabit Ethernet with PoE+ for high speed 802.11ac APs using existing cabling.
Power and performance
ProVision ASIC delivers more scalability, low latency and wire speed 40GbE.
Software-defined networking
The Aruba 3810 with industry standard OpenFlow, is ready for SDN applications such as HPE Network Visualizer, Optimizer, and Protector.
PHYSICAL INTERFACES
- 3810M 24G 1-slot Switch (JL071A)
- 24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 24 support MACSec
- 3810M 48G 1-slot Switch (JL072A)
- 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 48 support MACSec
- 3810M 24G PoE+ 1-slot Switch (JL073A)
- 24 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 24 support MACSec
- 3810M 48G PoE+ 1-slot Switch (JL074A)
- 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 48 support MACSec
- 3810M 16SFP+ 2-slot Switch (JL075A)
- 16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 16 support MACSec
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A)
- 40 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 40 support MACSec
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A)
- 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1-48 support MACSec
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A)
- 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Ports 1-48 support MACSec
- 3810M 24SFP+ 250W Switch (JL430A)
- 24 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1-24 support MACSec
ADDITIONAL PORTS AND SLOTS
- 1 stacking module slot
- 1 RJ-45 serial console port
- 1 RJ-45 out-of-band management port
- 1 dual-personality (RJ-45 or USB micro-B)
POWER SUPPLIES
- 2 power supply slots
- 1 minimum power supply required (ordered separately)
- Bundles (JL428A, JL429A, JL430A) include a power supply and uplink module(s)
MEMORY AND PROCESSOR
- P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card
- Dual ARM Cortex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal
PERFORMANCE
- IPv6 Ready Certified
- 1000 Mb Latency: < 2.8 µs (FIFO 64-byte packets)
- 10 Gbps Latency: < 1.8 µs (FIFO 64-byte packets)
- 40 Gbps Latency: < 1.5 µs (FIFO 64-byte packets)
- Routing table size: 10000 entries (IPv4), 5000 entries (IPv6)
- MAC address table size: 64000 entries
- Throughput:
- 3810M 24G 1-slot Switch (JL071A): up to 95.2 Mpps (64-byte packets)
- 3810M 48G 1-slot Switch (JL072A): up to 190.5 Mpps (64-byte packets)
- 3810M 24G PoE+ 1-slot Switch (JL073A): up to 95.2 Mpps (64-byte packets)
- 3810M 48G PoE+ 1-slot Switch (JL074A): up to 190.5 Mpps (64-byte packets)
- 3810M 16SFP+ 2-slot Switch (JL075A): up to 287.5 Mpps (64-byte packets)
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A): up to 273.8 Mpps (64-byte packets)
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A): up to 190.5 Mpps (64-byte packets)
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A): up to 190.5 Mpps (64-byte packets)
- 3810M 24SFP+ 250W Switch (JL430A): up to 285.7 Mpps (64-byte packets)
- Routing/Switching capacity:
- 3810M 24G 1-slot Switch (JL071A): 160 Gbps
- 3810M 48G 1-slot Switch (JL072A): 320 Gbps
- 3810M 24G PoE+ 1-slot Switch (JL073A): 160 Gbps
- 3810M 48G PoE+ 1-slot Switch (JL074A): 320 Gbps
- 3810M 16SFP+ 2-slot Switch (JL075A): 480 Gbps
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A): 480 Gbps
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A): 320 Gbps
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A): 320 Gbps
- 3810M 24SFP+ 250W Switch (JL430A): 480 Gbps
- Switch fabric speed:
- 3810M 24G 1-slot Switch (JL071A): 169 Gbps
- 3810M 48G 1-slot Switch (JL072A): 338 Gbps
- 3810M 24G PoE+ 1-slot Switch (JL073A): 169 Gbps
- 3810M 48G PoE+ 1-slot Switch (JL074A): 338 Gbps
- 3810M 16SFP+ 2-slot Switch (JL075A): 508 Gbps
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A): 508 Gbps
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A): 338Gbps
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A): 338Gbps
- 3810M 24SFP+ 250W Switch (JL430A): 508Gbps
DIMENSIONS
- (H) 4.39 cm x (W) 44.25 cm x (D) 43.13 cm (1.73″ x 17.42″ x 16.98″) (1U height)
- 3810M 24G 1-slot Switch (JL071A): 5.79 kg (12.76 lb)
- 3810M 48G 1-slot Switch (JL072A): 5.99 kg (13.20 lb)
- 3810M 24G PoE+ 1-slot Switch (JL073A): 5.91 kg (13.02 lb)
- 3810M 48G PoE+ 1-slot Switch (JL074A): 6.18 kg (13.62 lb)
- 3810M 16SFP+ 2-slot Switch (JL075A): 6.02 kg (13.28 lb)
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A): 6.17 kg (13.61 lb)
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A): 7.18 kg (15.82 lb)
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A): 7.23 kg (15.94 lb)
- 3810M 24SFP+ 250W Switch (JL430A): 508Gbps: 7.06 kg (15.56 lb)
INCLUDED ACCESSORIES
- Switch ships with 1 JL088A fan tray installed. Spares ordered separately.
- 1 fan tray slot
- Bundles (JL428A, JL429A, JL430A) include a power supply and uplink module(s)
MOUNTING AND ENCLOSURE
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal surface mounting only
ENVIRONMENTAL
- Operating temperature range: 0° C to 45° C (32°F to 113°F)
- Operating humidity: 15% to 95% @ 104°F (40°C), noncondensing
- Storage temperature range: -40° C to 70° C (-40°F to 158°F)
- Storage humidity: 15% to 90% @ 65°C (149°F), non-condensing
- Operating altitude: 10,000 feet
- Acoustic noise:
- 3810M 24G 1-slot Switch (JL071A): Power: 39 dB, Pressure: 22.8 dB
- 3810M 48G 1-slot Switch (JL072A): Power: 38 dB, Pressure: 21.8 dB
- 3810M 24G PoE+ 1-slot Switch (JL073A): Power: 48 dB, Pressure: 30.7 dB
- 3810M 48G PoE+ 1-slot Switch (JL074A): Power: 42 dB, Pressure: 26 dB
- 3810M 16SFP+ 2-slot Switch (JL075A): Power: 39 dB, Pressure: 22.3 d
- 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A): Power: 45 dB, Pressure: 27.9 Db
- 3810M 48G PoE+ 4sfp+ 680W Switch (JL428A): Power: 47 dB, Pressure: 29.4 dB
- 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A): Power: 47 dB, Pressure: 29.4 dB
- 3810M 24SFP+ 250W Switch (JL430A): 508Gbps: Power: 39 dB, Pressure: 22.3 Db
SAFETY CERTIFICATIONS
- EN 60950/IEC 60950, UL 60950
- CAN/CSA 22.2 No. 60950
- EN 60825
- 24G 1-slot Switch (JL071A), additionally: UL 60950-1; CSA 22.2 60950-1; EN 60950-1:2006+A11:2009+A1:2010+A12:2011
EMISSIONS
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013
IMMUNITY
- Generic: EN55022: 2010
- EN: EN55024: 2010
- ESD: IEC 61000-4-2
- Radiated: IEC 61000-4-3; 3 V/m
- EFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)
- Surge: IEC 61000-4-5; 1 kV/2 kV AC
- Conducted: IEC 61000-4-6; 3 V
- Power frequency magnetic field: IEC 61000-4-8; 1 A/m, 50 or 60 Hz
- Voltage dips and interruptions: IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods
- Harmonics: EN61000-3-2:2006 +A1:2009 +A2:2009 Class A
- Flicker: EN61000-3-3:2008
MANAGEMENT AND MONITORING
- Command line interface
- Graphical user interface (Web browser)
- AirWave network platform
- Central network management
- IMC – Intelligent Management Center
- Configuration menu
- Out-of-band management (RJ-45 Ethernet)
- In-line and out-of-band
- Out-of-band management (serial RS-232c or micro usb)
